What is a Business VoIP Phone System? A business VoIP phone is a communication service which provides data or calls packets across the internet. The VoIP technology utilises a digital signal data packet to convert into voice calls, it allows people to make phone calls...
Selecting a hosted VoIP solution for your business can remove a lot of burdens if you are stuck with the traditional phone system. It can be tough to break old habits, and one such habit is using traditional phones because they have been around for decades and you...
If you are thinking about switching your business communication system, then you have probably heard about VoIP phone Technology. VoIP phone system is a great alternative to the traditional telephone system for businesses. One may wonder what the benefits are of...
What is VoIP? VoIP technology unlike traditional phone services works by transmitting the audio over the internet. If you have ever used WhatsApp, Viber or Skype for making calls then you are aware how convenient and easy it is. Best of all through VoIP phone system...
VoIP Phone systems are more than 20 years old and are getting more powerful day by day. All this has happened because VoIP provides businesses with unique mobility. Furthermore, VoIP developers are continuously improving technology. Therefore, in this article, we are...
The Yealink VP59 Smart Video Phone is designed for executives and teleworkers that strikes the perfect balance between simplicity and sophistication, enabling high-quality communications for business executives and professionals alike.
Yealink VP59 Key Features
8 inch (1280 x 800) capacitive adjustable touch screen
1080p@30 full HD video
Runs Android 7.1
Built-in Bluetooth 4.2
Built-in dual band 2.4G/5G Wi-Fi (802.11a/b/g/n/ac)
USB 2.0 port for USB headset, media and storage applications
Up to 16 VoIP accounts
Standard HDMI output for monitor connection
Up to 3-party video conferencing
Up to 5-party video/audio mixed conferencing
PoE support
Based on Android 7.1 operating system, the VP59 features an eight-inch LCD touch screen that gives you a smartphone-like user experience, and it also supports the installation of third-party applications for business customisation as well as the DoorPhone features. When working with Yealink DD10K DECT USB Dongle, VP59 will turn into a corded-cordless phone and repay you up to 4 DECT handsets in total to meet your daily demands. Furthermore, the VP59 smart video phone boasts the 802.11 a/b/g/n/ac Wi-Fi connectivity as well as the Bluetooth 4.2 connectivity. This combination of advanced technology facilitates faster data transmissions and High Definition Multimedia Interface (HDMI) output for high quality media exchanges.
HD Audio and Video
The VP59 is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Noise Proof and Acoustic Shield technologies, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly. The solution also boasts a dynamic, removable 1080P HD camera for extraordinary, real-time face-to-face interactions.
Easy Collaboration
The VP59 not only furnishes you with the built-in Bluetooth 4.2 and the built-in dual band Wi-Fi, but also the HDMI output and the ability to function with Yealink VC Desktop together to share content from your laptop(1). Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your VP59 to the corded-cordless phone via DECT technology. Moreover, administrators can easily install additional 3rd –party Android applications, like Skype, SFB, to improve collaboration and productivity. And it offers local HD call recording and screenshot capabilities on their USB flash drive as well.
High Security and Interoperability
The Yealink VP59 addresses the need for heightened digital security by using SIP over Transport Layer Security (TLS/SSL), significantly enhancing data protection. The device is not only secure, but also flexible; VP59 supports broad interoperability with leading video conferencing systems and IP-PBX/UC systems on the market, as well as with several leading softswitch providers.
Efficient Installation and Provisioning
The Yealink VP59 supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings.
The Yealink SIP-T58V is a simple-to-use smart media phone that provides an enriched HD audio and video conferencing experience for business professionals. The SIP-T58V features a 7″ (1024 x 600) capacitive adjustable touchscreen, 720p30 HD video and up to 16 VoIP accounts.
Yealink T58V Key Features
7 inch (1024 x 600) capacitive touch screen
Interoperable with 2N’s IP intercom system
5-Way Audio Conferencing
Built-in Bluetooth 4.0+ for headsets and pairing mobile devices
Built-in Wi-Fi (802.11b/g/n)
USB 2.0 port (2.0 compliant) for USB headset,media and storage applications
Up to 16 VoIP accounts
Based on Android 5.1.1 operating system, the SIP-T58V features a seven-inch adjustable multi-point touch screen, a removable two-megapixel HD camera CAM50, integrated Wi-Fi and Bluetooth 4.0+ EDR, and it is coupled with a built-in web browser, calendar, recorder and more, which also support the installation of third-party applications for business customisation. The Yealink SIP-T5 Smart Media Phone Series strikes an exquisite balance between simplicity and sophistication, offering an all-in-one communications solution for today’s busy executives, managers and teleworkers.
The Yealink SIP-T58A is a modern smart-media IP phone, that is feature rich and simple to use. Business users can benefit from an enhanced HD audio and visual communication experience and features such as 5-way audio conferencing and built-in Wi-Fi (802.11b/g/n).
Yealink T58A Key Features
7 inch (1024 x 600) capacitive touch screen
Interoperable with 2N’s IP intercom system
5-Way Audio Conferencing
Built-in Bluetooth 4.0+ for headsets and pairing mobile devices
Built-in Wi-Fi (802.11b/g/n)
USB 2.0 port (2.0 compliant) for USB headset,media and storage applications
Up to 16 VoIP accounts
Based on Android 5.1.1 operating system, the SIP-T58A features a seven-inch adjustable multi-point touch screen, integrated Wi-Fi and Bluetooth4.0+ EDR, and it is coupled with a built-in web browser, calendar, recorder and more, which also support the installation of third-party applications for business customisation. The Yealink SIP-T5 Smart Media Phone Series strikes an exquisite balance between simplicity and sophistication, offering an all-in-one communications solution for today’s busy executives, managers and teleworkers.
The Yealink SIP-T56A is a simple-to-use smart media phone that provides an enriched HD audio experience for business professionals. This all-new smart media phone enables productivity-enhancing visual communication with the ease of a standard phone.
Yealink T56A Key Features
Up to 16 VoIP accounts
7 inch (1024 x 600) capacitive touch screen
Interoperable with 2N’s IP intercom system
Built-in Bluetooth 4.0+ for headsets and pairing mobile devices
Built-in Wi-Fi (802.11b/g/n)
USB 2.0 port (2.0 compliant) for USB headset,media and storage applications
Up to 5-party audio conferencing
Wall mountable
The T56A features up to 16 VoIP accounts and a 7 inch (1024 x 600) capacitive touch screen. Based on Android 5.1.1 operating system, the SIP-T56A features a seven-inch fixed multi-point touch screen, integrated Wi-Fi and Bluetooth 4.0+ EDR, and it is coupled with a built-in web browser, calendar, recorder and more, which also support the installation of third-party applications for business customisation. The Yealink SIP-T5 Smart Media Phone Series strikes an exquisite balance between simplicity and sophistication, offering an all-in-one communications solution for today’s busy executives, managers and teleworkers.
The Yealink SIP-T57W is an easy-to-use Prime Business Phone with an adjustable 7-inch multi-point touch screen that you can not only easily and flexibly find the comfortable viewing angle according to the personal and environmental needs, but also get a rich visual presentation and easy navigation with just one-touch.
Yealink SIP-T57W Key Features
7” 800 x 480 capacitive adjustable touch screen
Adjustable LCD screen
Built-in dual band 2.4G/5G Wi-Fi (802.11a/b/g/n/ac)
Built-in Bluetooth 4.2
USB 2.0 port for USB recording, wired/wireless USB headsets and EXP50
Up to 16 VoIP accounts
Dual-port Gigabit Ethernet
PoE support
Paperless label design
HAC Handset
Wall mountable
With the built-in Bluetooth 4.2 and the built-in dual band 2.4G/5G Wi-Fi, the SIP-T57W IP Phone ensures you to keep up with the modern wireless technology and take the first chance in the future wireless age. Its built-in USB 2.0 port allows for USB recording or a direct wired/wireless USB headset or up to three Yealink EXP50 expansion modules connection. Benefitting from these features, the Yealink SIP-T57W is a powerful and expandable office phone that delivers optimum desktop efficiency and productivity.
Outstanding user experience
Yealink SIP-T57W IP Phone features an adjustable 7-inch capacitive touch screen that you can readily adjust it to the comfortable viewing angle according to yourself. In addition, clearly defined set of menus is easy to navigate through when all you have to do is touching the desired option, that ensuring you an optimised interface for smartphone-like user experience.
HD Audio
The SIP-T57W is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Acoustic Shield technology, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly.
Wireless Transmission
Yealink SIP-T57W IP Phone not only furnishes you with the built-in Bluetooth 4.2 for Bluetooth headsets and mobile contacts synchronisation but also the built-in dual band Wi-Fi for Wi-Fi connectivity, allowing you to access the 5G Wi-Fi connectivity handily. Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your IP phone to the corded-cordless phone via DECT technology. Moreover, the IP phone can function with Yealink VC Desktop together to share content from your laptop, making collaboration much easier than before.
High Expandability
A built-in USB 2.0 port allows you to enjoy USB call recording via USB flash drive. Via this USB port, you also can connect wired/wireless USB headset without connecting Yealink EHS36 anymore, and connect up to 3 Yealink expansion modules EXP50 which can be programmed with up to 180 paperless DSS keys.
Efficient Installation and Provisioning
The Yealink SIP-T57W supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings.
Audio Features
HD voice: HD handset, HD speaker
Hearing aid compatible (HAC) handset
Acoustic Shield
Full-duplex hands-free speakerphone with AEC
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
12 VoIP accounts
Call hold, mute, DND, redial, call return, auto answer
One-touch speed dial, call forward, call waiting, call transfer
Group listening, SMS, emergency call
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, XML Browser, Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Built-in dual band Wi-Fi
Network standard: IEEE802.11a/b/g/n/ac
Transmission Rate: Up to 433Mbps (dynamic)
Frequency range: 2.4GHz/5.0GHz
Built-in Bluetooth 4.2 for
Bluetooth headset
Mobile contacts synchronisation
Bluetooth call
USB port (2.0 compliant) for
Wired/wireless USB headset
USB call recording through USB flash drive
Colour-screen expansion modules EXP50 (up to 3)
Content Sharing (via Yealink VCD)
Enhanced DSS key
Corded-Cordless Phone (via DECT Dongle DD10K)
Up to 4 DECT cordless handsets
Up to 4 concurrent calls
Support Yealink W52H/W53H/W56H/DD Phone
Slave Handset for Master Deskset
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialling
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF), Bridged Line Apperance (BLA)
Anonymous call, anonymous call rejection
Hot-desking, voice mail
Flexible seating
Executive and Assistant
Call park, call pickup
Centralised call recording, call recording
Display and Indicator
7″ 800 x 480 capacitive adjustable touch screen
LED for call and message waiting indication
Dual-colour (red or green) illuminated LEDs for line status
Wallpaper
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Screensaver
Power saving
Feature Keys
29 one-touch DSS keys
7 features keys: mute, headset, message, redial, hands-free speakerphone
The Yealink SIP-T54W business IP Phone is an easy-to-use Prime Business Phone with an adjustable 4.3-inch colour LCD screen that you can easily and flexibly find the comfortable viewing angle according to the personal and environmental needs.
Yealink SIP-T54W Key Features
4.3″ 480 x 272-pixel colour display with backlight
Adjustable LCD screen
Built-in dual band 2.4G/5G Wi-Fi (802.11a/b/g/n/ac)
Built-in Bluetooth 4.2
USB 2.0 port for USB recording, wired/wireless USB headsets and EXP50
Up to 16 VoIP accounts
Dual-port Gigabit Ethernet
PoE support
Paperless label design
HAC Handset
Wall mountable
With the built-in Bluetooth 4.2 and the built-in dual-band 2.4G/5G Wi-Fi, the SIP-T54W IP Phone ensures you to keep up with the modern wireless technology and take the first chance in the future wireless age. Its built-in USB 2.0 port allows for USB recording or a direct wired/wireless USB headset or up to three Yealink EXP50 expansion modules connection. Benefitting from these features, the Yealink SIP-T54W is a powerful and expandable office phone that delivers optimum desktop efficiency and productivity.
User Friendly
Yealink SIP-T54W IP Phone features an adjustable 4.3-inch colour LCD screen that you can readily adjust it to the comfortable viewing angle according to yourself. As to the audio quality, the SIP-T54W is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Acoustic Shield technology, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly.
Wireless Transmission
Yealink SIP-T54W IP Phone not only furnishes you with the built-in Bluetooth 4.2 for Bluetooth headsets and mobile contacts synchronisation but also the built-in dual-band Wi-Fi for Wi-Fi connectivity, allowing you to access the 5G Wi-Fi connectivity handily. Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your IP phone to the corded-cordless phone via DECT technology. Moreover, the IP phone can function with Yealink VC Desktop together to share content from your laptop, making collaboration much easier than before.
High Expandability
A built-in USB 2.0 port allows you to enjoy USB call recording via USB flash drive. Via this USB port, you also can connect wired/wireless USB headset without connecting Yealink EHS36 anymore, and connect up to 3 Yealink expansion modules EXP50 which can be programmed with up to 180 paperless DSS keys.
Efficient Installation and Provisioning
he Yealink SIP-T53W supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings.
Audio Features
HD voice: HD handset, HD speaker
Hearing aid compatible (HAC) handset
Acoustic Shield
Full-duplex hands-free speakerphone with AEC
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
12 VoIP accounts
Call hold, mute, DND, redial, call return, auto answer
One-touch speed dial, call forward, call waiting, call transfer
Group listening, SMS, emergency call
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, XML Browser, Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Built-in dual band Wi-Fi
Network standard: IEEE802.11a/b/g/n/ac
Transmission Rate: Up to 433Mbps (dynamic)
Frequency range: 2.4GHz/5.0GHz
Built-in Bluetooth 4.2 for
Bluetooth headset
Mobile contacts synchronisation
Bluetooth call
USB port (2.0 compliant) for
Wired/wireless USB headset
USB call recording through USB flash drive
Colour-screen expansion modules EXP50 (up to 3)
Content Sharing (via Yealink VCD)
Enhanced DSS key
Corded-Cordless Phone (via DECT Dongle DD10K)
Up to 4 DECT cordless handsets
Up to 4 concurrent calls
Support Yealink W52H/W53H/W56H/DD Phone
Slave Handset for Master Deskset
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialling
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Hot-desking, voice mail
Flexible seating
Executive and Assistant
Call park, call pickup
Centralised call recording, call recording
Display and Indicator
4.3″ 480 x 272-pixel colour display with backlight
16-bit depth colour
LED for call and message waiting indication
Dual-colour (red or green) illuminated LEDs for line status
Wallpaper
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
10 line keys with LED
10 line keys can be programmed up to 21 various features (3-page view)
7 features keys: mute, headset, message, redial, hands-free speakerphone
The Yealink SIP-T53W is an easy-to-use Prime Business Phone with an adjustable 3.7-inch graphical LCD that you can easily and flexibly find the comfortable viewing angle according to the personal and environmental needs.
Yealink T53 Key Features
Up to 16 SIP accounts
3.7″ 360x160-pixel graphical LCD with backlight
Adjustable LCD screen
Built-in dual band 2.4G/5G Wi-Fi (802.11a/b/g/n/ac)
Built-in Bluetooth 4.2
USB 2.0 port for USB recording, wired/wireless USB headsets and EXP50
Up to 12 VoIP accounts
Dual-port Gigabit Ethernet
PoE support
Paperless label design
HAC Handset
Wall mountable
With the built-in Bluetooth 4.2 and the built-in dual-band 2.4G/5G Wi-Fi, the SIP-T53W IP Phone ensures you to keep up with the modern wireless technology and take the first chance in the future wireless age. Its built-in USB 2.0 port allows for USB recording or a direct wired/wireless USB headset or up to three Yealink EXP50 expansion modules connection. Benefitting from these features, the Yealink SIP-T53W is a powerful and expandable office phone that delivers optimum desktop efficient and productivity
User Friendly
Yealink SIP-T53W IP Phone features an adjustable 3.7-inch graphical LCD that you can readily adjust it to the comfortable viewing angle according to yourself. As to the audio quality, the SIP-T53W is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Acoustic Shield technology, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly.
Wireless Transmission
Yealink SIP-T53W IP Phone not only furnishes you with the built-in Bluetooth 4.2 for Bluetooth headsets and mobile contacts synchronization, but also the built-in dual band Wi-Fi for Wi-Fi connectivity, allowing you to access the 5G Wi-Fi connectivity handily. Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your IP phone to the corded-cordless phone via DECT technology. Moreover, the IP phone can function with Yealink VC Desktop together to share content from your laptop, making collaboration much easier than before
High Expandability
A built-in USB 2.0 port allows you to enjoy USB call recording via USB flash drive. Via this USB port, you also can connect wired/wireless USB headset without connecting Yealink EHS36 anymore, and connect up to 3 Yealink expansion modules EXP50 which can be programmed with up to 180 paperless DSS keys.
Efficient Installation and Provisioning
he Yealink SIP-T53W supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings.
Audio Features
HD voice: HD handset, HD speaker
Hearing aid compatible (HAC) handset
Acoustic Shield
Full-duplex hands-free speakerphone with AEC
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
12 VoIP accounts
Call hold, mute, DND, redial, call return, auto answer
One-touch speed dial, call forward, call waiting, call transfer
Group listening, SMS, emergency call
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, XML Browser, Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Built-in dual band Wi-Fi
Network standard: IEEE802.11a/b/g/n/ac
Transmission Rate: Up to 433Mbps (dynamic)
Frequency range: 2.4GHz/5.0GHz
Built-in Bluetooth 4.2 for
Bluetooth headset
Mobile contacts synchronisation
Bluetooth call
USB port (2.0 compliant) for
Wired/wireless USB headset
USB call recording through USB flash drive
Colour-screen expansion modules EXP50 (up to 3)
Content Sharing (via Yealink VCD)
Enhanced DSS key
Corded-Cordless Phone (via DECT Dongle DD10K)
Up to 4 DECT cordless handsets
Up to 4 concurrent calls
Support Yealink W52H/W53H/W56H/DD Phone
Slave Handset for Master Deskset
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialling
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Hot-desking, voice mail
Flexible seating
Executive and Assistant
Call park, call pickup
Centralised call recording, call recording
Display and Indicator
3.7″ 360x160-pixel graphical LCD with backlight
LED for call and message waiting indication
Dual-colour (red or green) illuminated LEDs for line status
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
8 line keys with LED
8 line keys can be programmed up to 21 various features (3-page view)
5 features keys: mute, headset, message, redial, hands-free speakerphone
The Yealink SIP-T53 is an easy-to-use Prime Business Phone with an adjustable 3.7-inch graphical LCD that you can easily and flexibly find the comfortable viewing angle according to the personal and environmental needs.
Yealink T53 Key Features
Up to 16 SIP accounts
3.7″ 360x160-pixel graphical LCD with backlight
Adjustable LCD screen
Up to 12 VoIP accounts
Dual-port Gigabit Ethernet
PoE support
Paperless label design
Wi-Fi via WF40/WF50
Bluetooth via BT40
USB 2.0 port for USB recording, wired/wireless USB headsets and EXP50
Wall mountable
Working with Yealink Bluetooth USB Dongle BT40 and Yealink Wi-Fi USB Dongle WF40/WF50, the SIP-T53 IP Phone ensures you to keep up with the modern wireless technology and take the first chance in the future wireless age. Its built-in USB 2.0 port allows for USB recording or a direct wired/wireless USB headset or up to three Yealink EXP50 expansion modules connection. Benefitting from these features, the Yealink SIP-T53 is a powerful and expandable office phone that delivers optimum desktop efficient and productivity.
User Friendly
Yealink SIP-T53 IP Phone features an adjustable 3.7-inch graphical LCD that you can readily adjust it to the comfortable viewing angle according to yourself. As to the audio quality, the SIP-T53 is coupled with the latest version of Yealink Optimal HD Voice technologies, including Yealink Acoustic Shield technology, that effectively eliminate background distractions and noises, deliver crystal clear voice even in a noisy environment. Meanwhile, complying with the latest Hearing Aid Compatibility (HAC) Regulations, its HAC handset helps the person who is with hearing loss to hear the voice more clearly.
Wireless Transmission
Yealink SIP-T53 IP Phone not only furnishes you with the Bluetooth connectivity, including Bluetooth headsets and mobile contacts synchronization, when working with Yealink Bluetooth USB Dongle BT40, but also the Wi-Fi connectivity when working with Yealink Wi-Fi USB Dongle WF40/WF50. Notably, you can access the 5G Wi-Fi connectivity handily if you use WF50. Also if you want to expand your horizons for busy environments, or, share one phone system with your small team by adding multiple handsets, just simply turn your IP phone to the corded-cordless phone via DECT technology. Moreover, the IP phone can function with Yealink VC Desktop together to share content from your laptop, making collaboration much easier than before.
High Expandability
A built-in USB 2.0 port allows you to enjoy USB call recording via USB flash drive. Via this USB port, you also can connect wired/wireless USB headset without connecting Yealink EHS36 anymore, and connect up to 3 Yealink expansion modules EXP50 which can be programmed with up to 180 paperless DSS keys.
Efficient Installation and Provisioning
The Yealink SIP-T53 supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realise the Zero Touch Provisioning without any complex manual settings.
The Yealink T48S IP Phone is a dynamic business communications solution for executives and professionals. The T48S features up to 16 SIP accounts a 7″ 800 x 480-pixel colour touch screen with backlight, has dual-port gigabit ethernet ports and offers much more..
Yealink T48S Key Features
Up to 16 SIP accounts
7″ 800 x 480-pixel colour touch screen with backlight
Opus* codec support
USB 2.0
T4S Auto-P template unified
T4S firmware unified
Dual-port Gigabit Ethernet
PoE support
Paperless label design
Headset, EHS support
Wi-Fi via WF40
Bluetooth via BT40
USB recording
Supports expansion modules
Stand with two adjustable angles
Wall mountable
The SIP-T48S comes with Yealink’s Optima HD Voice technology and wideband codec of Opus for unparalleled audio clarity. Phone users will think they are sitting in the same room with one another. The phone uses Gigabit Ethernet technology for rapid call handling. Plus, it works in conjunction with Bluetooth USB Dongle and Wi-Fi USB Dongle.
Audio Features
HD voice: HD handset, HD speaker
Codecs: G.722, G.711(A/μ), G.723.1,
Full-duplex hands-free speakerphone with AEC
DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
16 VoIP accounts
Call hold, mute, DND
One-touch speed dial, hotline
Call forward, call waiting, call transfer
Group listening, SMS, emergency call
Redial, call return, auto answer
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, XML Browser, Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Intelligent search method
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Remote office, hot-desking
Message Waiting Indicator (MWI)
Voicemail, call park, call pickup
Intercom, paging, music on hold
Call completion, call recording
Display and Indicator
7” 800 x 480-pixel colour touch screen with backlight
24 bit depth colour
LED for call and message waiting indication
Wallpaper
Intuitive user interface with icons and soft keys
National language selection
Caller ID with name, number and photo
Feature Keys
29 one-touch DSS keys
7 features keys: message, headset,
hold, mute, transfer, redial, hands-free
6 navigation keys
volume control keys
Illuminated mute key
Illuminated headset key
Illuminated hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af), Class 3
Built-in a USB port, support Bluetooth
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
Supports up to 6 Expansion Modules for an attendant console application
Other Physical Features
Wall mountable
External universal AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch, TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
Package Features
Qty/CTN: 5 PCS
N.W/CTN: 8.2 kg
NAT traveral: STUN mode
G.W/CTN: 9 kg
Giftbox size: 324mm*263mm*128mm
Carton Meas: 660mm*338mm*273mm
Product DetailsTechnical Specifications
The Yealink T48G is an elegant high-level IP Phone that is ideal executives and busy professionals. The Yealink SFB Phone is an exceptional member of the Yealink T4x Series and an excellent choice for professionals who need the features of a high-end modern phone.
Yealink T48G Key Features
Dual-port Gigabit Ethernet, Power over Ethernet
7” 800 x 480-pixel colour touchscreen with backlight
HD Voice: HD Codec, HD speaker, HD handset
6 VoIP accounts, BLF/BLA, IPV6, Open VPN
Supports Bluetooth Headsets
Easy collaboration with Microsoft Skype for Business / Lync
Features include easy collaboration with Microsoft Skype for Business / Lync and outstanding HD audio performance.
The Yealink T48G incorporates a USB port allowing Bluetooth headsets to be connected via the Yealink BT40 Bluetooth dongle. Autoprovisioning and manual programming follow the same format as the rest of the Yealink range, making life simpler for installers and technicians.
The Yealink T48GN is a Skype For Business Phone and is certified compatible with 3CX, Asterisk and BroadSoft BroadWorks, along with many more IP PBX and hosted platforms, making it the ideal choice for busy managers
Please refer to the Yealink VoIP Phone Range Detailed Comparison Table to compare Yealink IP Phones.
Audio Features
HD voice: HD handset, HD speaker
Codecs: G.722, G.711(A/μ), G.723.1,
G.729AB, G.726, iLBC
DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
6 VoIP accounts
Call hold, mute, DND
One-touch speed dial, hotline
Call forward, call waiting, call transfer
Group listening, SMS, emergency call
Redial, call return, auto answer
Mute, auto answer, DND
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, XML Browser, Action URL/URI
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialing
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Remote office, hot-desking
Message Waiting Indicator (MWI)
Voicemail, call park, call pickup
Intercom, paging, music on hold
Call completion, call recording
Display and Indicator
7” 800 x 480-pixel colour touch screen with backlight
24 bit depth colour
LED for call and message waiting indication
Wallpaper
Intuitive user interface with icons and soft keys
National language selection
Caller ID with name, number and photo
Power saving
Screensaver
Feature Keys
29 one-touch DSS keys
7 features keys: message, headset,
hold, mute, transfer, redial, hands-free
speakerphone
6 navigation keys
volume control keys
Illuminated mute key
Illuminated headset key
Illuminated hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af), Class 3
Built-in a USB port, support Bluetooth
headset (Through USB Dongle)
1 x USB port (2.0 compliant)
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
Supports up to 6 Expansion Modules for a receptionist console application
Other Physical Features
Wall mountable
External universal AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
Product DetailsTechnical Specifications
The Yealink T46S IP phone is the ultimate communications tool for busy executives and professionals. In addition to offering better overall performance than the T46G, the T46S features up to 16 SIP accounts, 4.3″ 480 x 272-pixel colour display with backlight and dual-port gigabit ethernet.
Yealink T46S Key Features
Up to 16 SIP accounts
4.3″ 480 x 272-pixel colour display with backlight
Opus* codec support
Dual-port Gigabit Ethernet
USB 2.0
T4S Auto-P template unified
T4S firmware unified
PoE support
Paperless label design
Headset, EHS support
Wi-Fi via WF40
Bluetooth via BT40
USB recording
Supports expansion modules
Stand with 2 adjustable angles
The new T4S series offers the same elegant appearance of the T4 line, but with improvements for greater interoperability and collaboration. The SIP-T46S is also built with Gigabit Ethernet technology, for rapid call handling and use with accessories like a Bluetooth USB Dongle and a Wi-Fi USB Dongle.
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
16 VoIP accounts
Call hold, mute, DND
One-touch speed dial, hotline
Group listening, SMS, emergency call
Redial, call return, auto answer
Mute, auto answer, DND
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Hotline, emergency call
Dial plan, XML Browser, Action URL/URI
USB port (2.0 compliant): Bluetooth earphone through BT40 (pending), Wi-Fi through WF40 (pending), USB call recording through USB flash drive (pending)
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Enhanced DSS key
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialing
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Hot-desking, emergency call
Call park, call pickup
Flexible seating
Executive and Assistant
Centralized call recording
Visual Voice Mail
Call recording
Display and Indicator
4.3″ 480 x 272-pixel colour display with backlight
16 bit depth colour
LED for call and message waiting indication
Dual-color (red or green) illuminated LEDs for
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Screensaver
Feature Keys
10 line keys with LED
6 line keys can be programmed up to 15 paperless DSS keys (3-page view)
5 features keys: message, headset, mute, redial, hands-free speakerphone
4 context-sensitive “soft” keys
6 navigation keys
volume control keys
Illuminated mute key
Illuminated headset key
Illuminated hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af), Class 2
1 x USB port (2.0 compliant)
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
1 x RJ12 (6P6C) EXT port: Supports up to 6 Expansion Modules for an attendant console application
Other Physical Features
Stand with 2 adjustable angles
Wall mountable
External Yealink AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Yealink SIP-T46S IP phone
Handset with handset cord
Ethernet Cable (2m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Wall Mount Bracket (Optional)
Product DetailsTechnical Specifications
The Yealink T42S IP phone is a dynamic business communications tool for superior voice communications and extended functionality.
Yealink T42S Key Features
Up to 12 SIP accounts
2.7″ 192x64-pixel graphical LCD with backlight
Opus* codec support
Dual-port Gigabit Ethernet
USB 2.0
T4S Auto-P template unified
T4S firmware unified
PoE support
Paperless label design
Headset, EHS support
Integrated stand with 2 adjustable angles
Wall mountable
The SIP-T42S is a 12-line IP phone with multiple programmable keys for enhancing productivity. It features Yealink Optima HD Voice Technology and wideband codec of Opus for superb sound quality and crystal clear communications.
The T42S has a faster, more responsive interface than the T42G and offers better overall performance
The SIP-T42S is built with Gigabit Ethernet technology for rapid call handling. Plus, with an all-new USB port, the SIP-T42S boasts unparalleled functionality and expansibility, which comes ready for future Bluetooth, Wi-Fi and USB recording features.
The new T4S series offers the same elegant appearance of the T4 line, but with improvements for greater interoperability and collaboration.
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
12 VoIP accounts
One-touch speed dial, redial
Call forward, call waiting
Call transfer, call hold
Call return, group listening
Mute, auto answer, DND
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Hotline, emergency call
Dial plan, XML Browser, Action URL/URI
USB port (2.0 compliant): Bluetooth earphone through BT40 (pending), Wi-Fi through WF40 (pending), USB call recording through USB flash drive (pending)
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Enhanced DSS key
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Smart dialing
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Hot-desking, emergency call
Call park, call pickup
Flexible seating
Executive and Assistant
Centralized call recording
Visual Voice Mail
Call recording
Display and Indicator
2.7″ 192x64-pixel graphical LCD with backlight
LED for call and message waiting indication
Dual-color (red or green) illuminated LEDs for
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
6 line keys with LED
6 line keys can be programmed up to 15 paperless DSS keys (3-page view)
5 features keys: message, headset, mute, redial, hands-free speakerphone
4 context-sensitive “soft” keys
6 navigation keys
2 volume control keys
Illuminated mute key
Illuminated headset key
Illuminated hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af), Class 2
1 x USB port (2.0 compliant)
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
Other Physical Features
Stand with 2 adjustable angles
Wall mountable
External Yealink AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Yealink SIP-T42S IP phone
Handset with handset cord
Ethernet Cable (2m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Wall Mount Bracket (Optional)
Product DetailsTechnical Specifications
The Yealink T40G is an entry-level SIP desk phone with a host of features and advanced capabilities. Support for up to 3 SIP accounts and 2 x Gigabit Ethernet ports for high-speed connectivity are some of the main features business users can expect from this affordable VoIP Phone.
Yealink T40G Key Features
Up to 3 SIP accounts
2.3″ 132 x 64-pixel graphical LCD with backlight
Opus* codec support
Dual-port Gigabit Ethernet
Local phone book up to 1000 entries (search/import/export features)
Intuitive user interface with icons and soft keys
3 programmable line keys with dual-colour illuminated LEDs for line status information
Paperless label design
3-way conference call
Featuring a backlit graphical LCD display and Opus codec support, the T40G has superb audio quality and a rich visual experience. Thanks to its paperless design, it has 3 programmable memory keys for your own customisation, plus 3-way conferencing, BLF’s and an intuitive user interface.
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
3 VoIP accounts
One-touch speed dial, redial
Call forward, call waiting
Call transfer, call hold
Call return, group listening
Mute, auto answer, DND
Direct IP call without SIP proxy
3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Hotline, emergency call
Dial plan,
XML Browser
Action URL/URI
RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)
Enhanced DSS key
Directory
Local phonebook up to 1000 entries
Blacklist
XML/LDAP remote phonebook
Intelligent search method
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF)
Anonymous call, anonymous call rejection
Bridged Line Apperance (BLA)
Hot-desking, emergency call
Message Waiting Indicator (MWI)
Call park, call pickup
Intercom, paging, music on hold
Flexible seating
Executive and Assistant
Centralized call recording
Visual Voice Mail
Display and Indicator
2.3” 132x64-pixel graphical LCD with backlight
LED for call and message waiting indication
Dual-color (red or green) illuminated LEDs for
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
3 line keys with LED
5 features keys: message, headset, mute, redial, hands-free speakerphone
4 context-sensitive “soft” keys
6 navigation keys
2 volume control keys
mute key
headset key
hands-free speakerphone key
Interface
Dual-port Gigabit Ethernet
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
Power over Ethernet (IEEE 802.3af), Class 2
Other Physical Features
Stand with 2 adjustable angles
Wall mountable
External Yealink AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Broadsoft device management
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Yealink SIP-T40G IP phone
Handset with handset cord
Ethernet Cable (1.5m CAT5E UTP Cable)
Stand
Quick Start Guide
Wall Mount Bracket (Optional)
Product DetailsTechnical Specifications
The Yealink T41S is a feature-rich business tool for superior communications and extended functionality. The SIP-T41S is a six-line IP phone that comes with built-in programmable keys to enhance productivity.
Yealink T41S Key Features
Up to 6 SIP accounts
2.7″ 192x64-pixel graphical LCD with backlight
Opus* codec support
USB 2.0
T4S Auto-P template unified
T4S firmware unified
PoE support
Paperless label design
Headset, EHS support
Integrated stand with 2 adjustable angles
Wall mountable
With an all-new USB port, the SIP-T41S boasts unparalleled functionality and expansibility, which comes ready for future Bluetooth, Wi-Fi and USB recording features.
The new T4S series offers the same elegant appearance of the T4 line, but with improvements for greater interoperability and collaboration. The SIP-T41S features Yealink Optima HD Voice technology and wideband codec of Opus delivers superb audio quality and crystal clear voice communications. The T41S offers a faster, more-responsive interface than the T41P and several performance-enhancing functions.
External Yealink AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T): 212mm*189mm*175mm*54mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Broadsoft device management
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Yealink SIP-T41S IP phone
Handset with handset cord
Ethernet Cable (1.5m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Wall Mount Bracket (Optional)
Product DetailsTechnical Specifications
The Yealink T29G IP Phone is an advanced T2x Yealink VoIP Phone. The SIP-T29G is a gigabit VoIP phone with a 4.3″ 480 x 272 -pixel colour display. The T29G has HD voice and features up to 16 SIP accounts.
Yealink T29G Key Feature
16 SIP accounts
Yealink Optima HD voice
3.66″ 240x120-pixel graphical LCD with backlight
Yealink HD Voice
Built-in a USB port, support
Bluetooth headset (Through USB Dongle)
Headset, EHS support
IPv6 support
Integrated stand with 2 adjustable angles
PoE support
Wall mountable (optional)
Supports expansion modules
Simple, flexible and secure provisioning options
The Yealink T29G supports Gigabit Ethernet, a variety of device connections, including EHS headset and USB. With programmable keys, the T29G IP Phone supports vast productivity-enhancing features.
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
Physical Features
Stand with 2 adjustable angles
Wall mountable
External universal AC adapter (optional):AC 100~240V input and DC 5V/2A output
Power consumption (PSU): 1.8-5.4W
Power consumption (PoE): 2.1-8.0W
Dimension(W*D*H*T):244mm*213mm*185mm*54mm
Operating temperature: -10~50°C
Product DetailsTechnical Specifications
The Yealink T27G Gigabit IP Phone is a 6 line VoIP phone with unparalleled functionality and expansibility thanks to an all-new USB port. A professional IP Phone with features such as 3.66″ 240x120-pixel graphical LCD with backlight and 2 x Gigabit Ethernet Ports. The SIP-T27G is future proof and ready for prospective Bluetooth, Wi-Fi and USB recording features.
Yealink T27G Key Features
6 SIP accounts
Yealink Optima HD voice
3.66″ 240x120-pixel graphical LCD with backlight
Yealink HD Voice
Gigabit
USB 2.0
Opus* codec support
IPv6 support
Paper label free design
PoE support
Headset, EHS support
Supports expansion modules
Seamlessly migrated to GigE-based network infrastructure, SIP-T27G IP phone is also built with the Gigabit Ethernet facilitating very rapidly call handling. By using standard encryption protocols, the SIP-T27G performs highly secure remote provisioning and software upgrades.
Power over Ethernet (IEEE 802.3af), Class 2
1 x USB port (2.0 compliant)
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
1 x RJ12 (6P6C) EHS port
1 x RJ12 (6P6C) EXT port: Supports up to 6 Expansion Modules
Other Physical Features
Wall mountable
External Yealink AC adapter (optional): AC 100~240V input and DC 5V/1.2A output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T):
Dimension (W*D*H*T): 265mm x 210mm x 170.5mm x 53.5mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Package content
Yealink SIP-T27G IP phone
Handset with handset cord
Ethernet Cable (1.5m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Qty/CTN: 5 PCS
N.W/CTN: 6.6 kg
G.W/CTN: 7.4 kg
Giftbox size: 295mm x 224mm x 115mm
Carton Meas: 602mm x 308mm x 236mm
Product DetailsTechnical Specifications
The Yealink T23G IP Phone features an intuitive user interface and enhanced functionality, making it easy for people to interact and maximise productivity. As a cost-effective IP solution, the T23G helps users to streamline business processes, deliver a powerful, secure and consistent communication experience for small and large office environments.
Yealink T23G Key Features
Up to 3 SIP accounts
132x64-pixel graphical LCD
Dual-port Gigabit Ethernet
Yealink HD Voice
Supports Dual-color LEDs
Headset support
Wall mountable
IPv6 support
Paperless design
Simple, flexible and secure provisioning options
The T23G features Yealink HD technology which enables rich, clear, life-like voice communications, outsourced management options, flexible deployment and third-party communications applications.
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
3 SIP accounts
Call hold, mute, DND
One-touch speed dial, hotline
Call forward, call waiting, call transfer
Group listening, SMS
Redial, call return, auto answer
Direct IP call without SIP proxy
Local 3-way conferencing
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan, off hook hot line
XML Browser, action URL/URI
Integrated screenshots
RTCP-XR
Enhanced DSS Key
Directory
Local phonebook up to 1000 entries
Blacklist
XML remote phonebook
Smart dialing
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Busy Lamp Field (BLF), Bridged Line Apperance(BLA)
Anonymous call, anonymous call rejection
Hot-desking, emergency call
Message Waiting Indicator (MWI)
Voice mail, call park, call pickup
Intercom, paging, music on hold
Call completion, call recording
Flexible seating
Executive and Assistant
Centralized call recording
Visual Voice Mail
Display and Indicator
132 x 64-pixel graphical LCD with backlight
LED for call and message waiting indication
Dual-color (red or green) illuminated LEDs for
line status information
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
3 line keys with LED
5 features keys: message, headset, redial, mute, hands-free speakerphone
6 navigation keys
Volume control keys
Interface
Dual-port Gigabit Ethernet
Power over Ethernet (IEEE 802.3af), class 1
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
Other Physical Features
Wall mountable
External Yealink AC adapter (optional)
AC 100~240V input and DC 5V/600mA output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Dimension (W*D*H*T):
Dimension (W*D*H*T)
209mm*188mm*150mm*41mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Network and Security
SIP v1 (RFC2543), v2 (RFC3261)
Call server redundancy supported
NAT traveral: STUN mode
Proxy mode and peer-to-peer SIP link mode
IP assignment: static/DHCP
Time and date synchronization using SNTP
HTTP/HTTPS web server
UDP/TCP/DNS-SRV (RFC 3263)
QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
SRTP for voice
Transport Layer Security (TLS)
HTTPS certificate manager
AES encryption for configuration file
Digest authentication using MD5/MD5-sess
OpenVPN, IEEE802.1X
IPv6
LLDP/CDP/DHCP VLAN
ICE
Package Features
Package content
Yealink SIP-T23G IP phone
Handset with handset cord
Ethernet Cable (1.5m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Product DetailsTechnical Specifications
The Yealink SIP-T19P E2 Single Line VoIP Phone is an entry-level VoIP phone featuring a 132 x 64-pixel graphical LCD, dual 10/100 Ethernet ports and full-duplex speakerphone.
Yealink T19P (SIP-T19P) Key Features
1 Line Appearances
Dual-port 10/100 Ethernet
Single SIP account
Full-duplex hands-free speakerphone
No expansion modules supported
RJ9 Headset PortDesktop with footstand (detachable), Wall-mountable
Supports PoE, Power Supply available separately
Dual 10/100 Mbps network ports with integrated PoE are ideal for extended network use. The SIP-T19P supports a single VoIP account, simple, flexible and secure installation options, plus IPv6 and SRTP/ HTTPS/ TLS, VLAN and QoS. It includes headset use, is wall-mountable and has been designed very specifically for better business.
DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
Full-duplex hands-free speakerphone with AEC
VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
1 VoIP account
Call hold, mute, DND
One-touch speed dial, hotline
Call forward, call waiting, call transfer
Group listening, SMS
Redial, call return, auto answer
Direct IP call without SIP proxy
Call forward, call waiting, call transfer
Ring tone selection/import/delete
Set date time manually or automatically
Dial plan
XML Browser, action URL/URI
Integrated screenshots
RTCP-XR
Enhanced DSS Key
Directory
Local phonebook up to 1000 entries
Blacklist
XML remote phonebook
Smart dialing
Phonebook search/import/export
Call history: dialed/received/missed/forwarded
IP-PBX Features
Anonymous call, anonymous call rejection
Hot-desking, emergency call
Message Waiting Indicator (MWI)
Voice mail, call park, call pickup
Intercom, paging, music on hold
Call completion
Flexible seating
Executive and Assistant
Centralized call recording
Visual Voice Mail
Display and Indicator
132x64-pixel graphical LCD
LED for call and message waiting indication
Intuitive user interface with icons and soft keys
Multilingual user interface
Caller ID with name and number
Power saving
Feature Keys
6 features keys: message, headset, redial, mute, hands-free speakerphone
5 navigation keys
Volume control keys
Interface
2 x RJ45 10/100M Ethernet ports
Power over Ethernet (IEEE 802.3af), class 1
1 x RJ9 (4P4C) handset port
1 x RJ9 (4P4C) headset port
Other Physical Features
Wall mountable
External Yealink AC adapter (optional)
AC 100~240V input and DC 5V/600mA output
Power consumption (PSU): 0.9-1.3W
Power consumption (PoE): 1.2-1.8W
Volume control keys
Dimension (W*D*H*T)
185mm*188mm*143mm*38mm
Operating humidity: 10~95%
Operating temperature: -10~50°C (+14~122°F)
Management
Configuration: browser/phone/auto-provision
Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
Auto-provision with PnP
Zero-sp-touch,TR-069
Phone lock for personal privacy protection
Reset to factory, reboot
Package tracing export, system log
Package Features
Package content
Handset with handset cord
Ethernet Cable (1.5m CAT5E UTP Cable)
Stand
Quick Start Guide
Power Adapter (Optional)
Product DetailsTechnical Specifications
The Yealink T21P E2 IP Phone is a 2-line entry level VoIP phone that offers a smooth user experience. The T21P E2 features a phone directory, HD-Voice, a 5-line graphical LCD screen and supports PoE.
Yealink T21P Key Features
1 Line Appearances
Dual-port 10/100 Ethernet
Single SIP account
Full-duplex hands-free speakerphone
No expansion modules supported
RJ9 Headset Port
132x64-pixel graphical LCD display with backlight
Wall mountable
HD Audio
Yealink HD voice refers to the combination of software and hardware design as well as the implementation of wideband technology to maximize the acoustic performance. Coupled with advanced acoustic clarity technology such as full duplex, echo cancellation, adaptive jitter buffer, etc, the SIP-T21P E2 provides clearer, more lifelike voice communications.
Enhanced Call Management
The SIP-T21P E2 supports vast productivity-enhancing features such as XML Browser, callpark, call pickup, BLF, call forward, call transfer, 3-way conference, which makes it the natural and obvious efficiency tool for today’s busy small and large offices environment.
Efficient Installation and Provisioning
The Yealink SIP-T21P E2 supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realise the Zero Touch Provisioning without any complex manual settings, which makes the SIP-T21P E2 simple to deploy, easy to maintain and upgrade.
Highly secure transport and interoperability
The communicator uses SIP over Transport Layer Security (TLS/SSL) to provide service providers with the latest technology for enhanced network security. The range is certified compatible with 3CX and Broadsoft Broadworks, ensuring excellent compatibility with leading soft switch suppliers.
